Disc Cycle Cross carbon frame FM286
Category: Cycle Cross Frame  Publish Time: 2016-01-08 09:59

Disc Cycle Cross carbon frame FM286
142*12mm Disc cyclocross carbon frame



Item  FM286

Size:48cm,50cm,52cm,54cm,56cm,58cm

Weave: UD matte finish

Type:Thru axle cyclocross

Material:Hight Modulus Toray Carbon Fiber T700

Brake Type:Disc Brake (front and rear 160mm rotor)

Frame rear spacer:142mmX12mm thru axle OR 9*135MM QR

Fork spacer :100mmX15mm thru axle

Head tube:Taper 1-1/8” to 1-1/2”

Seat Tube:For diameter 27.2mm seat post

Cable:Internal cable

Groupset:Di2 and Machine compatible

Bottom Bracket: BB30 and BSA bottom bracket

Tire size:700X38C

Warranty:2 years





the competitive advantage of product line:



Our products are mainly exported to North America, Western Europe and Northern Europe. We are capable of designing and building our own customized products, and are also able to offer ODM service upon our customers' request.
